Automatic Connector Assembly Machine for Switch

Function:

PLC (Programmable Logic Controller) control system,to achieve the automatic material feeding with thermostat switch base, left and right conducting plate, left and right static wafers,left and right magnetic rod, left and right located block, connecting screws and other supporting components. After the assembly, the machine will proceed with automatic detection of products.

Application:

Apply to the manufacture field of thermostat switch, to complete the automatic assembly of thermal switch.

Technical Specifications:
Production Capacity: 20-25pcs/min
Driving Pressure: 4.5-6.5kgf/cm2
Working Voltage: 110V-250V
Feeding Mode: automatic feeding by vibrating tray
Dimension : 2000(L)X1400(W)X1600(H)(mm)
Weight: About 500KGS

Machine Structure:
1 Electronic control: Taiwan Weinview touch screen, PLC control;
2 Gas into components: AIRTAC brand cylinder drive, Panasonic or Keyence optical fiber sensor;
3 Two to four vibrator automatic feeding rubber core, terminal, vibration plate painting, baking rack side pass;
4 Structure sliding part choose D2 high speed steel, stable wear, good fixity;
5 One year warranty, wearing parts warranty for six months;
6 Alarm indication;

Features:

1 This series machine is designed and manufactured specifically for the switching industry
2 Automatic feed terminal, loaded terminal / riveting / complete
3. Automatic detection,auto start when there is material, auto cut off when no material detected
4. Automatic counting, set output
5 Using the touch screen, intuitive interface, simple and safe operation
6 Reporting irregular operation and giving the relative solutions in the form of message.
